From the June 2016 issue

Missing petals

Thoughts on a coronal hole during totality.
By | Published: June 27, 2016 | Last updated on May 18, 2023
T he grandeur and brevity of a total solar eclipse can replace thought with raw emotion, especially if it’s a first-time experience. The more eclipses one sees, however, the more sanity leaks back into the moment, infusing the mind with kernels of critical thinking. Thankfully, I found enough sanity during totality March 9, 2016, to ponder a dramatic visual phenomenon that may be related to the ultraviolet and X-ray energy the Sun produces.

Fortunate sighting
I watched totality free from clouds, sailing in a “banana boat” off the coast of the little island of Ternate, Indonesia. My partner and eclipse veteran Deborah Carter was with me, as were two new friends whom we met on the island.

The chase afforded us little time for preparing gear in the narrow and unstable boat. And good thing we didn’t take much time because we cleared the clouds with only seconds remaining before second contact. Adding to the joy of this success was seeing the Moon near perigee, slamming the door on the Sun’s light as the solar corona swelled magnificently into view.

A plucked daisy
To the unaided eye, the equatorial streamers appeared long and dramatic, with one extraordinarily bright streamer extending to the southwest. These streamers formed the brightest part of a largely symmetrical corona. It consisted of numerous overlapping petals, like those of a frosted dahlia in bloom — except for the corona south of the Sun’s polar region, where the petals appeared to have been “plucked.” It was all but a visual black hole with only the faintest of plumes (comet-like plumes) extending tail-like into space.

Total solar eclipse of March 9, 2016
This Solar and Heliospheric Observatory image of the Sun, taken during totality of the March 9, 2016, total solar eclipse, shows a definite fading of the corona (a coronal hole) to the south, which is toward the lower right in this image.
Of the dozen times I’ve seen the solar corona during eclipses, I do not recall such a striking area devoid of detail. The magnitude of the void was brought home when Deborah also commented on it after the eclipse, wondering what could have caused such an absence of light when the remainder of the corona was so petal rich.

We appear to be on the downside of a solar maximum, a time when the corona typically bursts forth with streamers radiating from all points of the solar disk. Therefore, the dahlia flower arrangement of coronal petals was expected. Nevertheless, the Sun’s corona is not entirely uniform. Coronal holes, for instance, form predominantly at the Sun’s poles, and the one that appeared at the Sun’s south pole during the eclipse might have been responsible for the corona’s vanishing act.

A different kind
of black hole

The corona is both hot (on the order of 1 million degrees Fahrenheit) and delicate — a million times fainter than the Sun’s photosphere, which is why we see it only during totality. The corona’s intensity is also not uniform, having darker (cooler) areas caused by regions with lower density. On ultraviolet and X-ray images, they appear as “black holes” against the bright corona owing to the lower temperature of the plasma (much as sunspots appear darker against the Sun’s photosphere).

Unlike the equatorial streamers — which form closed magnetic loops and heat up the corona, causing it to glow brightly — coronal holes mark where magnetic field lines expand freely into space without looping back. During eclipses, we can see these open magnetic field lines as polar plumes — the fragile, comet-like polar tails that reached out from the Sun’s south pole during the March 9 eclipse. Indeed, when I compared a SOHO spacecraft ultraviolet image of the Sun taken on the day of totality, I found that a coronal hole was present at Sun’s south pole, which may have contributed to the extreme darkening of the corona at that point.

As usual, send your thoughts and observations to
