Venus transit and lunar mirror help astronomers find worlds around other stars

A team of astronomers used the opportunity to look at the sunlight reflected off the Moon to see how it changed during the transit, a technique that could help scientists find planets in orbit around other stars.
By | Published: December 14, 2012 | Last updated on May 18, 2023

On June 6, 2012, Venus passed directly between Earth and the Sun in a so-called transit where the planet appears as a silhouette against the solar disk, something that will not happen again until December 5, 2117. A team of Italian astronomers led by Paolo Molaro of the National Institute of Astrophysics at the University of Trieste used the opportunity to perform an unusual and challenging experiment, looking at the sunlight reflected off the Moon (moonlight) to see how it changed during the transit. This technique could help scientists find planets in orbit around other stars.

When Venus passes in front of the Sun, it hides a part of our star’s rotating surface. Because of rotation, the spectrum of the Sun — created splitting the different colors of light using a spectrograph — is slightly different on each side. On one side, the solar surface is rotating toward the observer, so its light will be “blueshifted,” meaning the lines seen in a spectrum move toward shorter wavelengths. On the other, the surface is rotating away from the observer, so its light is “redshifted,” meaning that the lines move toward longer wavelengths.

By looking at the reflected light from the lunar surface, this is averaged out as a broadening of the various lines. When Venus moves in front of the Sun from east to west, it first blocks out the surface moving toward us and then the surface moving away from us. This causes a distortion in the spectral lines known as the “Rossiter-McLaughlin effect.”

The astronomers realized that the High Accuracy Radial Velocity Planet Searcher (HARPS) spectrograph installed on a 3.6-meter telescope at La Silla in Chile, part of the European Southern Observatory (ESO), would be sensitive enough to detect the effect and that the Moon would be in the right place, too. The Moon was slightly ahead of Earth in its orbit, so they saw the transit a couple of hours later than terrestrial observers. This also meant that the Moon was in the nighttime sky in Chile, making it possible for the La Silla telescope to operate safely and observe the change in the solar spectrum.

Distortions in the spectral lines resulting from the Rossiter-McLaughlin effect are extremely small and are equivalent to a 1.9 mph (3 km/h) shift in the observed motion of the Sun. It has been seen before in binary systems where the two stars eclipse each other. But it becomes more and more difficult to observe when the celestial body is a planet; rather than being the size of Jupiter, it is similar in size to Earth as is Venus. Scientists should nonetheless be able to measure the extent of this weak effect on the light from other planetary systems using telescopes such as the European Extremely Large Telescope (E-ELT) now under development. With the technique, it should be possible to characterize important features of these systems and thus improve our understanding of the formation of planets in general.

Lorenzo Monaco from ESO described how important HARPS was in their work. “The measured magnitude of the Rossiter-McLaughlin effect is comparable to being able to track the speed of a person walking at a slow pace at a distance of 93 million miles (150 million km), the space that separates us from the Sun,” said Monaco. “Nowadays, there are very few instruments capable of recording such tiny changes, especially if you only have a few hours to measure them.”

“There is close agreement between our work and the theoretical models,” said Mauro Barbieri from University of Padua in Italy. “Among other things, this change in velocity is comparable with that due to the natural expansion and contraction of our star. Our observations however have allowed us to clearly see the Rossiter-McLaughlin effect during the transit.”

“This measurement shows the sensational results that spectrographs on telescopes like E-ELT will be able to deliver,” said Molaro. ”We will open a new horizon in the study of the other Earth-like planets that are almost certainly waiting to be found around other stars in our galaxy.”

Transit-of-Venus
The Transit of Venus of June 6, 2012, as seen from Wiltshire in the United Kingdom. // Credit: Grant Privett
