Elusive matter found to be abundant far above Earth

Scientists found that cold plasma was altering the structure of electrical fields around the Cluster satellite; once they understood that, they used their field measurements to reveal the presence of once-hidden ions.
By | Published: January 24, 2012 | Last updated on May 18, 2023
Cluster satellite
A rendering of the Cluster satellite, designed to measure electric fields, which Andre and Cully used to detect low-energy ions high above the Earth. Credit: European Space Agency
Cold plasma has been well hidden. Space physicists have long lacked clues to how much of this electrically charged gas exists tens of thousands of miles above Earth and how the stuff may impact our planet’s interaction with the Sun. Now, a new method developed by Swedish researchers makes cold plasma measurable and reveals significantly more cold, charged ions in Earth’s upper altitudes than previously imagined.

At these lofty elevations, storms of high-energy-charged particles — space weather — roil the atmosphere, creating aurorae, buffeting satellites, and sometimes wreaking havoc with electronic devices and electric grids on Earth. The new evidence of abundant cold — low-energy — ions may change our understanding of this tumultuous space weather and lead to more accurate forecasting of it, scientists say. The finding also might shed light on what’s happening around other planets and moons – for instance, helping explain why the once robust atmosphere of Mars is so wispy today.

“The more you look for low-energy ions, the more you find,” said Mats Andre from the Swedish Institute of Space Physics in Uppsala, Sweden. “We didn’t know how much was out there. It’s more than even I thought.”

The low-energy ions are created in the ionosphere, a region of the upper atmosphere where solar energy can sweep electrons away from molecules, leaving atoms of elements like hydrogen and oxygen with positive charges. Actually detecting these ions at high altitudes has been extremely difficult.

Now that has changed, making it apparent that low-energy ions abound in the distant reaches where Earth’s atmosphere gives way to outer space. Researchers knew the ions were present at altitudes of about 60 miles (100 kilometers), but Andre and his colleague Chris Cully looked much higher, between 12,400 to 60,000 miles (20,000 to 100,000 km). While the concentration of the previously hidden cold ions varies, about 50 to 70 percent of the time, the particles make up most of the mass of great swaths of space, according to the researchers’ satellite measurements and calculations. And, in some high-altitude zones, low-energy ions dominate nearly all of the time. Even at altitudes around 62,000 miles (100,000km) — about a third of the distance to the Moon — the team detected these previously elusive low-energy ions.

Finding so many relatively cool ions in those regions is surprising, Andre said, because there’s so much energy blasting into Earth’s high altitudes from the solar wind — a rushing flow of hot plasma streaming from the Sun, which stirs up space-weather storms.

This hot plasma is about 1,000 times hotter than what Andre considers cold plasma — but even cold is a relative term. The low-energy ions have an energy that would correspond to about 900,000° Fahrenheit (500,000° Celsius) at typical gas densities found on Earth. But because the density of the ions in space is so low, satellites and spacecraft can orbit without bursting into flames.

For decades, space physicists have struggled to accurately detect low-energy ions and determine how much of the material is leaving our atmosphere. The satellite Andre works on, one of four European Space Agency Cluster spacecraft, is equipped with a detector with thin wire arms that measures the electric field between them as the satellite rotates. But when the scientists gathered data from their detectors, two mysterious trends appeared. Strong electric fields turned up in unexpected regions of space. And as the spacecraft rotated, measurements of the electric field didn’t fluctuate in the smoothly changing manner that Andre expected.

“To a scientist, it looked pretty ugly,” Andre said. “We tried to figure out what was wrong with the instrument. Then we realized there’s nothing wrong with the instrument.” Unexpectedly, they found that cold plasma was altering the structure of electrical fields around the satellite. Once they understood that, they could use their field measurements to reveal the presence of the once-hidden ions.

It’s a clever way of turning the limitations of a spacecraft-based detector into assets, said Thomas Moore from NASA’s Goddard Space Flight Center in Greenbelt, Maryland.

As scientists use the new measurement method to map cold plasma around Earth, they could discover more about how hot and cold plasmas interact during space storms and other events, deepening researchers’understanding of space weather, Andre said.

The new measurements indicate that about 2 pounds (0.9 kilogram) of cold plasma escapes from Earth’s atmosphere every second, Andre said.
Knowing that rate of loss for Earth may help scientists better reconstruct what became of the atmosphere of Mars, which is thought to once have been denser and more similar to Earth’s. The new cold plasma results might also help researchers explain atmospheric traits of other planets and moons, Andre suggested.

And closer to home, if scientists could develop more accurate space-weather forecasts, they could save satellites from being blinded or destroyed, and better warn space station astronauts and airlines of danger from high-energy radiation. While low-energy ions are not responsible for the damage caused by space weather, they do influence that weather. Andre compared the swaths of ions to, say, a low-pressure area in our familiar, down-to-Earth weather — as opposed to a harmful storm. It is a key player, even if it doesn’t cause the damage itself. “You may want to know where the low-pressure area is to predict a storm,” Andre noted.

Improving space-weather forecasts to the point where they’re comparable to ordinary weather forecasting is “not even remotely possible if you’re missing most of your plasma,” said Moore from NASA. Now, with a way to measure cold plasma, the goal of high-quality forecasts is one step closer.

“It is stuff we couldn’t see and couldn’t detect, and then suddenly we could measure it,” Moore said of the low-energy ions. “Now you can actually study it and see if it agrees with the theories.”
