ALMA discovers a formation site of a giant planetary system

Astronomers found that it is highly possible that Jupiter-like or Earth-like planets are forming in an asymmetric ring around the star HD 142527.
By | Published: January 23, 2014 | Last updated on May 18, 2023
HD 142527 disk
Dust and gas disk around HD 142527. The dust and gas distributions observed by ALMA are shown in red and green, respectively. Near-infrared image taken by the Subaru Telescope is shown in blue. The image clearly shows that the dust is concentrated in the northern (upper) part of the disk.
ALMA (ESO/NAOJ/NRAO)/NAOJ/Fukagawa, et al.
A team of Japanese astronomers has obtained firm evidence of formation of a giant planetary system around a young star by the observations with the Atacama Large Millimeter/submillimeter Array (ALMA). This result has a transformative impact on the theories of planet formation and gives us a clue to the origin of a wide variety of planetary systems.

The research team, led by astronomers at Osaka University and Ibaraki University, observed with ALMA a young star named HD 142527 in the constellation Lupus the Wolf. The ALMA image shows that cosmic dust, which is component material of planets, is circling around the star in a form of an asymmetric ring. By measuring the density of dust in the densest part of the ring, the astronomers found that it is highly possible that Jupiter-like giant gaseous planets or Earth-like rocky planets are now being formed in that region. This region is far from the central star, about five times larger than the distance between the Sun and Neptune. This is the first firm evidence of planet formation found so far from the central star in a protoplanetary disk. The research team plans further observations of HD 142527 with ALMA for closer investigation, as well as other protoplanetary disks to have a comprehensive understanding of the planet formation in general.

More than 1,000 extrasolar planets have been discovered until now, and it is widely recognized that the Sun is not the only star which has planets. In the research of extrasolar planets, astronomers have found a wide variety of planets, such as Jupiter-like gaseous giant planets circling around central stars in a much smaller orbit than that of Mercury and planets that have a very large orbit far beyond the Neptune’s orbit. While such a diverse range of extrasolar planets have been discovered, the formation process of planets is yet to be well understood. This is one of the top priority issues in modern astronomy, and scientists have conducted an increasing number of observations to explore the planet-forming region around young stars.

A baby star is surrounded by a ring of dust and gas, which would be the component material of planets. Recent near-infrared observations with the Subaru Telescope revealed that protoplanetary disks have structures that are far more complex than scientists expected. Spiral or gap structures are thought to be associated with hidden planets in the disk. However, it is impossible to measure the amount of dust and gas in the densest part of the disk by near-infrared observations. Since near-infrared light is easily absorbed or scattered by a large amount of dust, it isn’t suitable for observing the innermost part of the dense region of the disk. Then, the key to the solution will be millimeter and submillimeter wave lengths, which can be observed with ALMA. Millimeter/submillimeter radiation has a longer wavelength than near-infrared light and is poorly absorbed by dust, which enables astronomers to peer into the inner part of the disk. Low spatial resolution was a weak point in millimeter/submillimeter observations, but it is now greatly improved by ALMA.

Observations with ALMA
The research team selected the young star HD 142527 in the constellation Lupus the Wolf as a target of their ALMA observations. Through their prior observations of the disk around HD 142527 with the Subaru Telescope, they discovered a gap inside the disk and peculiar shape of the outer disk. ALMA detected the submillimeter emission from the dust ring around the star. The emission has a nonuniform distribution, and the northern side is 30 times brighter than the faint southern side. “We are very surprised at the brightness of the northern side,” said Misato Fukagawa from Osaka University. “The brightest part in submillimeter wave is located far from the central star, and the distance is comparable to five times the distance between the Sun and Neptune. I have never seen such a bright knot in such a distant position. This strong submillimeter emission can be interpreted as an indication that a large amount of material is accumulated in this position. When a sufficient amount of material is accumulated, planets or comets can be formed here. To investigate this possibility, we measured the amount of material.”

In calculating the amount of material based on the submillimeter emission strength, the temperature of the material is an important parameter. The team estimated the temperature in the dense region from the observations of isotopomers of carbon monoxide. As a result, the team reached two possibilities — formation of gaseous giant planet or rocky planet. If the abundance of dust and gas is comparable to that in typical environment in the universe — the mass ratio of dust and gas is 1 to 100 — the dense region is massive enough to attract a large amount of gas due to the self-gravity and form giant gaseous planets several times more massive than Jupiter. Although this is similar to the formation process of stars in cosmic clouds, it was the first time that the possibility of such a planet formation process was directly suggested by observations of protoplanetary disks. The other possibility is the formation of a “dust trap” in which the abundance of dust is exceptionally higher than the other part of the disk. If the dust trap is formed in the disk, Earth-like rocky planets, small bodies such as comets, or cores of gaseous planets may be formed. In both cases, it is highly possible that planets are being formed in the dense part of the disk around HD 142527.

Researchers predicted theoretically the basics of the two planet-formation processes mentioned above were predicted theoretically more than 30 years ago. Astronomers assume that the planet formation of our solar system began with collision and coalescence of huge amounts of dust; then the concentration of dust would grow into a number of cores of planets — protoplanets — and these cores would evolve into planets through numerous collisions and coalescences. Some of the cores would capture massive atmospheres to form gaseous giants. It was thought that both of the processes occur close to the central star — around the Jupiter and Saturn orbit — in planetary systems similar to our solar system, but the new ALMA results undermine this conventional assumption. “Seeing the site of planet formation directly is one of the most important goals for ALMA,” said Munetake Momose from Ibaraki University. “Our observations successfully located a unique candidate in an unexpectedly distant place from the central star. I believe that ALMA will bring us more surprising results.”

Future prospects
The research team found out two possibilities in the planet formation process, which is taking place in the disk around HD 142527. The next step will be a precise measurement of the amount of gas to identify which process is involved. The team will continue detailed observations using ALMA with improved capability. “HD 142527 is a peculiar object, as far as our limited knowledge goes,” said Fukagawa. “However, other asymmetrical protoplanetary disks have been discovered since the early ALMA science operation started. Our final goal is to reveal the major physical process that controls the formation of planets. To achieve this goal, it is important to obtain a comprehensive view of planet formation through observations of many protoplanetary disks. We hope to be part of this great venture.”

Artist’s impression of the disk around HD 142527. The young star HD 142527 is surrounded by the dust and gas disk. A number of small dust particles in the disk collide and coalesce together to form protoplanets. // Credit: NAOJ
