What the Apollo Moon rocks told us

Buried within the Apollo samples that came back to Earth were the clues of lunar origins.
By | Published: June 21, 2019 | Last updated on May 18, 2023

Apollomoonrocks
Astronaut Alan Shepard prepares a tool used to help him collect rock samples from the surface of the Moon during Apollo 14.
NASA
Among the fruits of more than 80 hours the Apollo astronauts spent on the lunar surface were the treasures that came home. All told, the explorers carted back 842 pounds (382 kilograms) of Moon rocks, some 2,200 separate samples from six different lunar sites. It took years, but properly interpreting these rocks gave us the biggest scientific result from the entire Apollo program: understanding how the Moon formed.

Returning lunar samples was a priority from the beginning. One of the first things Neil Armstrong did after his descent down the ladder was to pocket a specimen as the original collected piece of the Moon. The missions that followed Apollo 11 were far more aggressive, returning a wide variety of Moon rock samples, effectively opening a window into lunar geology.

From the outset, the Apollo astronauts used a variety of tools to collect their samples, including rakes, tongs, and scoops. Astronauts searched a variety of geological features, too, hoping to assemble a suite of lunar minerals and rocks of different ages.

The youngest areas of the Moon are the mare, the lowlands, that filled with basaltic lava relatively late in the Moon’s formation. They typically consist of rocks that are 3.2 billion years old, whereas rocks from the older lunar highlands date to some 4.4 billion years ago. The youngest geological actions on the Moon, based on crater counts, probably were lava flows about 1.2 billion years ago. But, alas, we have no samples of these very young lunar rocks.

What exactly do Moon rocks look like? They are mostly grayish, and include many basalts, and breccias (rocks made up of broken and reassembled pieces), and mafic plutonic rocks from the highlands. This last type formed underground and were pushed up by the forces that created the lunar mountain ranges.

Mineralogically, most Moon rocks are pretty simple. Common lunar minerals include silicates, made up of silicon and other elements like calcium, aluminum, oxygen, magnesium, and iron. (Examples of silicates are plagioclase feldspars, pyroxenes, and olivine, the latter a mineral also commonly found in some types of meteorites.)

lunarsamples
A smattering of lunar samples collected during the Apollo missions. The small cubes are included for scale, and they measure 0.4 inches (1 cm) on a side.
NASA/David Kring
As the Apollo missions matured, the astronauts could carry back larger volumes of samples. The Apollo 11 astronauts returned some 48 pounds (22 kg) of rocks; Apollo 12, 76 pounds (34 kg); Apollo 14, 94 pounds (43 kg); Apollo 15, 169 pounds (77 kg); Apollo 16, 210 pounds (95 kg); and Apollo 17, 243 pounds (110 kg). The Moon rocks were carefully wrapped and set into containers to prevent contamination, then sent away to a storage facility at the Johnson Space Center in Houston, where they reside today. Well, mostly: Some Apollo samples are periodically loaned out to museums or for research, and sadly, some lunar samples have been stolen, or turned up missing.

Along the trail of discovery, some Moon rocks have better stories than others. Genesis Rock, collected near Spur Crater by Jim Irwin and Dave Scott during Apollo 15, was originally considered extremely old because of its strange, whitish, fractured appearance. The thick rock, measuring about 3.5 inches (9 cm) across, was later determined to be 4.1 billion years old, not as old the astronauts had hoped. But the talk and analysis of Genesis Rock has made it the most famous of all lunar specimens.

Another famous rock was collected during the last mission, Apollo 17, and designated sample 70017. It is a titanium-rich basalt from the Taurus-Littrow Valley, and after an initial analysis President Richard Nixon ordered the sample sliced up and distributed to the 50 States plus 135 foreign heads of state.

After all of this effort and journey, what did the Moon rocks tell us? Ultimately, they revealed Apollo’s biggest story, the origin of the Moon itself. The most striking analytical finding showed the samples are eerily similar to Earth rocks in several ways. The signature detail was that oxygen isotopes sealed in Moon rocks — the “flavors” of oxygen atoms — matched those on Earth. This and other factors led to scientists in the 1970s proposing what came to be called the Giant Impact Hypothesis. Planetary scientists believe the Moon likely formed when a Mars-sized body, which they have named Theia, struck a newborn Earth some 4.5 billion years ago. The collision produced a ring of debris surrounding the young planet, which eventually accreted into the Moon. Much of the mass of Theia was absorbed into early Earth. This idea explains the tremendous similarities between Earth and Moon rocks.

The collection of Apollo Moon rocks returned to Earth, mostly residing in Houston, has given planetary scientists their first detailed look at the geology of another world. As a result, they have a pretty good idea of how the Moon came to be. Thankfully, we can study lunar science in the peaceful current age, only imaging what a violent and dangerous place the early solar system was.
