Twin probes prepare for mission-ending Moon impact

The GRAIL spacecraft will conduct one final engineering experiment that could help future missions operate more efficiently before crashing into a lunar mountain.
By and | Published: December 14, 2012 | Last updated on May 18, 2023
This image shows the final flight path for NASA’s twin Gravity Recovery and Interior Laboratory (GRAIL) mission spacecraft, which will impact the Moon December 17, 2012. // Credit: NASA/JPL-Caltech/GSFC/ASU
Twin lunar-orbiting NASA spacecraft that have allowed scientists to learn more about the internal structure and composition of the Moon are being prepared for their controlled descent and impact on a mountain near the Moon’s north pole at about 5:28 p.m. EST Monday, December 17.

Ebb and Flow, the Gravity Recovery and Interior Laboratory (GRAIL) mission probes, are being sent purposely into the lunar surface because their low orbit and low fuel levels preclude further scientific operations. The duo’s successful prime and extended science missions generated the highest resolution gravity field map of any celestial body. The map will provide a better understanding of how Earth and other rocky planets in the solar system formed and evolved.

“It is going to be difficult to say goodbye,” said GRAIL principal investigator Maria Zuber of the Massachusetts Institute of Technology in Cambridge. “Our little robotic twins have been exemplary members of the GRAIL family, and planetary science has advanced in a major way because of their contributions.”

The mountain where the two spacecraft will make contact is located near a crater named Goldschmidt. Both spacecraft have been flying in formation around the Moon since January 1, 2012. They were named by elementary school students in Bozeman, Montana, who won a contest. The first probe to reach the Moon, Ebb, also will be the first to go down at 2:28 p.m. Flow will follow Ebb about 20 seconds later.

Both spacecraft will hit the surface at 3,760 mph (1.7 kilometers per second). No imagery of the impact is expected because the region will be in shadow at the time.

Ebb and Flow will conduct one final experiment before their mission ends. They will fire their main engines until their propellant tanks are empty to determine precisely the amount of fuel remaining in their tanks. This will help NASA engineers validate fuel consumption computer models to improve predictions of fuel needs for future missions.

“Our lunar twins may be in the twilight of their operational lives, but one thing is for sure, they are going down swinging,” said David Lehman of NASA’s Jet Propulsion Laboratory in Pasadena, California. “Even during the last half of their last orbit, we are going to do an engineering experiment that could help future missions operate more efficiently.”

Because the exact amount of fuel remaining aboard each spacecraft is unknown, mission navigators and engineers designed the depletion burn to allow the probes to descend gradually for several hours and skim the surface of the Moon until the elevated terrain of the target mountain gets in their way.

The burn that will change the spacecrafts’ orbit and ensure the impact is scheduled to take place Friday morning, December 14.

“Such a unique end-of-mission scenario requires extensive and detailed mission planning and navigation,” said Lehman. “We’ve had our share of challenges during this mission and always come through in flying colors, but nobody I know around here has ever flown into a Moon mountain before. It’ll be a first for us, that’s for sure.”

During their prime mission, from March through May, Ebb and Flow collected data while orbiting at an average altitude of 34 miles (55km). Their altitude was lowered to 14 miles (23km) for their extended mission, which began August 30 and sometimes placed them within a few miles of the Moon’s tallest surface features.

This animation shows the final flight path for NASA’s twin Gravity Recovery and Interior Laboratory (GRAIL) mission spacecraft, which will impact the moon December 17, 2012.

The animations were created from data obtained by NASA’s Lunar Reconnaissance Orbiter.

Image credit: NASA/JPL-Caltech/GSFC/ASU
