Research suggests water content of Moon interior underestimated

The volume of water molecules inside minerals could exceed the amount of water in the Great Lakes.Provided by NASA Headquarters, Washington, D.C.
By | Published: June 16, 2010 | Last updated on May 18, 2023
Moon imaged by Apollo 11
This photograph of the Full Moon was taken from Apollo 11 during its trip back to Earth.
June 16, 2010
NASA-funded scientists estimate from recent research that the volume of water molecules locked inside minerals in the Moon’s interior could exceed the amount of water in the Great Lakes.

Scientists at the Carnegie Institution’s Geophysical Laboratory in Washington, D.C., along with other scientists across the nation, determined that the water was likely present early in the Moon’s formation history as hot magma started to cool and crystallize. This finding means water is native to the Moon.

“For over 40 years, we thought the Moon was dry,” said Francis McCubbin of Carnegie. “In our study, we looked at hydroxyl, a compound with an oxygen atom bound with hydrogen, and apatite, a water-bearing mineral, in the assemblage of minerals we examined in two Apollo samples and a lunar meteorite.”

McCubbin’s team utilized tests that detect elements in the parts- per-billion range. Combining their measurements with models that characterize how the material crystallized as the Moon cooled during formation, they found that the minimum water content ranged from 64 parts per billion to 5 parts per million. The result is at least 2 orders of magnitude greater than previous results from lunar samples that estimated water content of the Moon to be less than 1 part per billion.

“In this case, when we talk about water on the Moon, we mean water in the structural form hydroxyl,” said Jim Green, director of the Planetary Science Division at NASA headquarters in Washington, D.C. “This is a very minor component of the rocks that make up the lunar interior.”

The origin of the Moon is now commonly believed to be the result of a Mars-sized object that impacted Earth 4.5 billion years ago. This impact put a large amount of material into Earth’s orbit that ultimately compacted to form the Moon. The lunar magma ocean that is thought to have formed at some point during the compacting process began to cool. During this cooling, water either escaped or was preserved as hydroxyl molecules in the crystallizing minerals.

Previous studies found evidence of water both on the lunar surface and inside the Moon by using remote sensing data from the Indian spacecraft Chandrayaan-1 and other lunar sample analysis.

Carnegie researchers looked within crystalline rocks called KREEP — K for potassium, REE for rare Earth elements, and P for phosphorus. These rocks are a component of some lunar impact melt and basaltic rocks.

“Since water is insoluble in the main silicates that crystallized, we believed that it should have concentrated in those rocks,” said Andrew Steele of Carnegie. “That’s why we selected KREEP to analyze.”

The identification of water from multiple types of lunar rocks that display a range of incompatible trace element signatures indicates that water may be at low concentrations but ubiquitous within the Moon’s interior, potentially as early as the time of lunar formation and magma ocean crystallization.

“It is gratifying to see this proof of the hydroxyl contents in lunar apatite,” said Bradley Jolliff at Washington University in St. Louis. “The concentrations are very low and, accordingly, they have been until recently nearly impossible to detect. We can now finally begin to consider the implications — and the origin — of water in the interior of the Moon.”
