Rosetta to deploy lander on November 12

Philae’s landing site, currently known as Site J, is located on the smaller of the comet’s two “lobes,” with a backup site on the larger lobe.
By | Published: September 30, 2014 | Last updated on May 18, 2023
Landing site J on Comet 67P
Rosetta’s navigation camera (NAVCAM) took this image of Comet 67P/Churyumov-Gerasimenko September 21, from a distance of 17.3 miles (27.8km) from the comet center. The image covers an area of about 1 x 1.2 miles (2 x 1.9 km) and focuses on the smaller of the two comet lobes. The primary landing site J is “above” the distinctive depression in this view.
The European Space Agency’s (ESA) Rosetta mission will deploy its lander, Philae, to the surface of Comet 67P/Churyumov-Gerasimenko on November 12.

Philae’s landing site, currently known as Site J, is located on the smaller of the comet’s two “lobes,” with a backup site on the larger lobe. The sites were selected just six weeks after Rosetta arrived at the comet on August 6, following its 10-year journey through the solar system.

In that time, the Rosetta mission has been conducting an unprecedented scientific analysis of the comet, a remnant of the solar system’s 4.6-billion-year history. The latest results from Rosetta will be presented on the occasion of the landing during dedicated press briefings.

The main focus to date has been to survey 67P/Churyumov-Gerasimenko in order to prepare for the first ever attempt to soft-land on a comet.

Site J was chosen unanimously over four other candidate sites as the primary landing site because the majority of terrain within a square kilometer area has slopes of less than 30° relative to the local vertical and because there are relatively few large boulders. The area also receives sufficient daily illumination to recharge Philae and continue surface science operations beyond the initial 64-hour battery-powered phase.

Over the last two weeks, the flight dynamics and operations teams at ESA have been making a detailed analysis of flight trajectories and timings for Rosetta to deliver the lander at the earliest possible opportunity.

Two robust landing scenarios have been identified, one for the primary site and one for the backup. Both anticipate separation and landing on November 12.

For the primary landing scenario, targeting Site J, Rosetta will release Philae at 9:35 CET at a distance of 14.0 miles (22.5 kilometers) from the center of the comet, landing about seven hours later. The one-way signal travel time between Rosetta and Earth on November 12 is 28 minutes and 20 seconds, meaning that confirmation of the landing will arrive at Earth ground stations at around 17:00 CET.

If a decision is made to use the backup Site C, separation will occur at 14:04 CET, 7.8 miles (12.5km) from the center of the comet. Landing will occur about four hours later, with confirmation on Earth at around 18:30 CET. The timings are subject to uncertainties of several minutes.

Final confirmation of the primary landing site and its landing scenario will be made October 14 after a formal Lander Operations Readiness Review, which will include the results of additional high-resolution analysis of the landing sites conducted in the meantime. Should the backup site be chosen at this stage, landing can still occur November 12.

A competition for the public to name the primary landing site will also be announced during the week of October 14.

The Rosetta orbiter will continue to study the comet and its environment using its 11 science instruments as they orbit the Sun together. The comet is on an elliptical 6.5-year orbit that takes it from beyond Jupiter at its farthest point to between the orbits of Mars and Earth at its closest to the Sun. Rosetta will accompany the comet for more than a year as they swing around the Sun and back to the outer solar system again.

The analyses made by the Rosetta orbiter will be complemented by the in-situ measurements performed by Philae’s 10 instruments.
