Giant cyclones imaged at Saturn’s poles

Near-infrared images from NASA's Cassini spacecraft create more questions about the Ringed World's weather systems.Provided by the Division for Planetary Sciences
By | Published: October 13, 2008 | Last updated on May 18, 2023

The 40th annual meeting of the Division for Planetary Sciences of the American Astronomical Society is going on in Ithaca, New York, until October 15. Visit Astronomy.com/News for regular updates from this conference.
Saturn's poles
These high-spatial-resolution polar orthographic projections of the north (left) and south (right) polar regions of Saturn show rings of clouds and hazes circling the poles, as observed in the near-infrared. The left image is the first detailed image of Saturn’s entire north polar region ever obtained. The south pole image (right), acquired just a few hours after the north polar image, also shows a polar cyclone, complete with a central eye clear of clouds. This cyclone extends out some 9,000 miles (15,000 kilometers) from the pole.
NASA/JPL/University of Arizona
October 13, 2008
New images from NASA’s Cassini spacecraft reveal a giant cyclone at Saturn’s north pole and show that earthlike storm patterns powered a similarly monstrous cyclone churning at Saturn’s south pole.

The new-found cyclone at Saturn’s north pole is only visible in the near-infrared wavelengths because the north pole is in winter, thus in darkness to visible-light cameras. At these wavelengths, about 7 times greater than light seen by the human eye, the clouds deep inside Saturn’s atmosphere are seen in silhouette against the background glow of Saturn’s internal heat.

Saturn’s entire north pole is now mapped in detail in infrared, with features as small as 75 miles (120 kilometers) visible in the images. Time-lapse movies of the clouds circling the north pole show the region’s whirlpool-like cyclone is rotating at 325 mph (530 km/h), more than twice as fast as the highest winds measured in cyclonic features on Earth. An odd, honeycomb-shaped hexagon surrounds the cyclone. This feature does not seem to move while the clouds within it whip around at high speeds, also greater than 300 mph (500 km/h). Oddly, neither the fast-moving clouds inside the hexagon nor this new cyclone seems to disrupt the six-sided hexagon.

Saturn's south pole
This detailed Cassini view of the monstrous vortex at Saturn’s south pole provides valuable insight about the mechanisms that power the planet’s atmosphere. It shows that what looked like puffy clouds at lower resolution are actually vigorous convective storms that form yet another distinct, inner ring.
NASA/JPL/Space Science Institute
New Cassini imagery of Saturn’s south pole shows complementary aspects of the region through the eyes of two different instruments. Near-infrared images from the visual and infrared mapping spectrometer instrument show the whole region is pockmarked with storms, while the imaging cameras show close-up details.

Unlike earthbound hurricanes, powered by the ocean’s heat and water, Saturn’s cyclones have no body of water at their bases, yet the eye-walls of Saturn’s and Earth’s storms look strikingly similar. The Ringed World’s hurricanes are locked to the planet’s poles, whereas terrestrial hurricanes drift across the ocean.

“These are truly massive cyclones, hundreds of times stronger than the most giant hurricanes on Earth,” said Kevin Baines, Cassini scientist on the visual and infrared mapping spectrometer at NASA’s Jet Propulsion Laboratory in Pasadena, California. “Dozens of puffy, convectively formed cumulus clouds swirl around both poles, betraying the presence of giant thunderstorms lurking beneath. Thunderstorms are the likely engine for these giant weather systems,” Baines said.

Just as condensing water in clouds on Earth powers hurricane vortices, the heat released from the condensing water in saturnian thunderstorms deep down in the atmosphere may be the primary power source energizing the vortex.

The new infrared images of the south pole, under the daylight conditions of southern summer, show that hundreds of dark cloud spots mark the entire. The clouds, similar to those at the north pole, are probably a manifestation of convective, thunderstorm-like processes extending some 62 miles (100 km) below the clouds. They are likely composed of ammonium hydrosulfide with possibly a mixture of materials dredged up from the depths. By contrast, planetary scientists suspect that ammonia — which condenses at high, visible altitudes — makes up most of Saturn’s hazes and clouds.

Saturn's south pole
These two images of Saturn show the entire south polar region, not just the little area around the core of the hurricane-like vortex. Earthlike storm patterns seem to be powering this vortex. The images were taken in the near-infrared on May 11, 2007, from a distance of 258,500 miles (416,000 kilometers), and with a phase angle of 36 degrees.
NASA/JPL/University of Arizona
Complementary images of the south pole from Cassini’s cameras, obtained in mid-July, are 10 times more detailed than any seen before. “What looked like puffy clouds in lower resolution images are turning out to be deep convective structures seen through the atmospheric haze,” said Cassini imaging team member Tony DelGenio of NASA’s Goddard Institute for Space Studies in New York. “One of them has punched through to a higher altitude and created its own little vortex.”

An outer ring of high clouds surrounds the “eye” of the vortex. The new images also hint at an inner ring of clouds about half the diameter of the main ring, and so the actual clear “eye” region is smaller than it appears in earlier low-resolution images.

“It’s like seeing into the eye of a hurricane,” said Andrew Ingersoll, a member of Cassini’s imaging team at the California Institute of Technology in Pasadena. “It’s surprising. Convection is an important part of the planet’s energy budget because the warm upwelling air carries heat from the interior. In a terrestrial hurricane, the convection occurs in the eye-wall; the eye is a region of down-welling. Here convection seems to occur in the eye as well.”

Further observations are planned to see how the features at both poles evolve as the seasons change from southern summer to fall in August 2009.
