NASA’s Phoenix Mars Lander detected snow falling from martian clouds. Spacecraft soil experiments also provided evidence of past interaction between minerals and liquid water — processes that occur on Earth.
A laser instrument designed to gather knowledge of how the martian atmosphere and surface interact detected snow from clouds about 2.5 miles (4 kilometers) above the Phoenix’s landing site. Data show the snow vaporizing before reaching the ground.
“Nothing like this view has ever been seen on Mars,” says Jim Whiteway, of York University, Toronto, lead scientist for the Canadian-supplied Meteorological Station on Phoenix. “We’ll be looking for signs that the snow may even reach the ground.”
Phoenix experiments also yielded clues pointing to calcium carbonate, the main composition of chalk, and particles that could be clay. Most carbonates and clays on Earth form only in the presence of liquid water.
“We are still collecting data and have lots of analysis ahead, but we are making good progress on the big questions we set out for ourselves,” says Phoenix Principal Investigator Peter Smith of the University of Arizona at Tucson.
Since landing on May 25, Phoenix has confirmed that a hard subsurface layer at its far-northern site contains water-ice. Determining whether that ice ever thaws would help answer whether the environment there has been favorable for life, a key aim of the mission.
The evidence for calcium carbonate in soil samples from trenches dug by the Phoenix robotic arm comes from two laboratory instruments called the Thermal and Evolved Gas Analyzer (TEGA) and the wet chemistry laboratory of the Microscopy, Electrochemistry and Conductivity Analyzer (MECA).
“We have found carbonate,” says William Boynton of the University of Arizona, lead scientist for the TEGA. “This points toward episodes of interaction with water in the past.”
The TEGA evidence for calcium carbonate came from a high-temperature release of carbon dioxide from soil samples. The temperature of the release matches a temperature known to decompose calcium carbonate and release carbon dioxide gas, which was identified by the instrument’s mass spectrometer.
The MECA evidence came from a buffering effect characteristic of calcium carbonate assessed in wet chemistry analysis of the soil. The measured concentration of calcium was exactly what would be expected for a solution buffered by calcium carbonate.
Both TEGA, and the microscopy part of MECA, have turned up hints of a clay-like substance.
“We are seeing smooth-surfaced, platy particles with the atomic-force microscope, not inconsistent with the appearance of clay particles,” says Michael Hecht, MECA lead scientist at NASA’s Jet Propulsion Laboratory in Pasadena, Calififornia.
The Phoenix mission, originally planned for 3 months on Mars, now is in its 5th month. However, it faces a decline in solar energy that is expected to curtail and then end the lander’s activities before the end of the year. Before power ceases, the Phoenix team will attempt to activate a microphone on the lander to possibly capture sounds on Mars.
“For nearly 3 months after landing, the Sun never went below the horizon at our landing site,” says Barry Goldstein, JPL Phoenix project manager. “Now it is gone for more than 4 hours each night, and the output from our solar panels is dropping each week. Before the end of October, there won’t be enough energy to keep using the robotic arm.”
