Does antimatter fall up or down?

All the evidence that gravity is the same for matter and antimatter is indirect, so scientists decided to use their ongoing anti-hydrogen research to tackle the question directly.
By | Published: April 30, 2013 | Last updated on May 18, 2023
Do atoms of anti-hydrogen weigh the same as atoms of ordinary hydrogen? Could they even have “negative” weight? Scientists from Berkeley Lab and UC Berkeley have used data from the ALPHA Experiment at CERN to measure antimatter gravity directly. // Illustration by Chukman So
The U.S. Department of Energy’s Lawrence Berkeley National Laboratory (Berkeley Lab) physicists and their colleagues in CERN’s ALPHA experiment present the first direct evidence of how atoms of antimatter interact with gravity.

The atoms that make up ordinary matter fall down, so do antimatter atoms fall up? Do they experience gravity the same way as ordinary atoms, or is there such a thing as antigravity?

These questions have long intrigued physicists, said Joel Fajans from Berkeley Lab because “in the unlikely event that antimatter falls upwards, we’d have to fundamentally revise our view of physics and rethink how the universe works.”

So far, all the evidence that gravity is the same for matter and antimatter is indirect, so Fajans and his colleague Jonathan Wurtele from Berkeley Lab decided to use their ongoing anti-hydrogen research to tackle the question directly. If gravity’s interaction with anti-atoms is unexpectedly strong, they realized, the anomaly would be noticeable in ALPHA’s existing data on 434 anti-atoms.

The first results, which measured the ratio of anti-hydrogen’s unknown gravitational mass (which comes from the force of gravity) to its known inertial mass (which comes from an applied force), did not settle the matter. Far from it. If an anti-hydrogen atom falls downward, its gravitational mass is no more than 110 times greater than its inertial mass. If it falls upward, its gravitational mass is at most 65 times greater.

What the results do show is that measuring antimatter gravity is possible, using an experimental method that points toward much greater precision in the future.

ALPHA creates anti-hydrogen atoms by uniting single antiprotons with single positrons — antielectrons — holding them in a strong magnetic trap. When the magnets are turned off, the anti-atoms soon touch the ordinary matter of the trap’s walls and annihilate in flashes of energy, pinpointing when and where they hit. In principle, if the experimenters knew an anti-atom’s precise location and velocity when the trap was turned off, they would only have to measure how long it takes to fall to the wall.

ALPHA’s magnetic fields don’t turn off instantly, however; almost 30-thousandths of a second passes before the fields decay to near zero. Meanwhile, flashes occur all over the trap walls at times and places that depend on the anti-atoms’ detailed but unknown initial locations, velocities, and energies.

“Late-escaping particles have very low energy, so gravity’s influence is more apparent on them,” said Wurtele. “But there were very few late escaping anti-atoms; only 23 of the 434 escaped after the field had been turned off for 20-thousandths of a second.”

Fajans and Wurtele worked with their ALPHA colleagues and with Berkeley Lab associates, UC Berkeley lecturer Andrew Charman and Andre Zhmoginov, to compare simulations with their data and separate gravity’s effects from those of magnetic field strength and particle energy. Much statistical uncertainty remained.

“Is there such a thing as antigravity? Based on free-fall tests so far, we can’t say yes or no,” said Fajans. “This is the first word, however, not the last.”

CERN is upgrading ALPHA to ALPHA-2, and precision tests may be possible in one to five years. The anti-atoms will be laser-cooled to reduce their energy while still in the trap, and the magnetic fields will decay more slowly when the trap is turned off, increasing the number of low-energy events. Questions physicists and non-physicists have been wondering about for more than 50 years will be subject to tests that are not only direct but could be definitive.
