A supernova cocoon breakthrough

The first X-ray evidence of a supernova shock wave breaking through a cocoon of gas may help astronomers understand why some supernovae are more powerful than others.
By and | Published: May 16, 2012 | Last updated on May 18, 2023
This supernova is called SN 2010jl and is found in a galaxy about 160 million light-years from Earth. SN 2010jl was first spotted by astronomers November 3, 2010, and probably exploded about a month before that. Credit: X-ray: NASA/CXC/Royal Military College of Canada/P.Chandra et al; Optical: NASA/STScI
Observations with NASA’s Chandra X-ray Observatory have provided the first X-ray evidence of a supernova shock wave breaking through a cocoon of gas surrounding the star that exploded. This discovery may help astronomers understand why some supernovae are more powerful than others.

On November 3, 2010, a supernova was discovered in the galaxy UGC 5189A, located about 160 million light-years away. Using data from the All Sky Automated Survey telescope in Hawaii taken earlier, astronomers determined that this supernova exploded in early October 2010 (in Earth’s time frame).

This composite image of UGC 5189A shows X-ray data from Chandra in purple and optical data from the Hubble Space Telescope in red, green, and blue. SN 2010jl is the bright X-ray source near the top of the galaxy.

A team of researchers used Chandra to observe this supernova in December 2010 and again in October 2011. The supernova was one of the most luminous that has ever been detected in X-rays.

In optical light, SN 2010jl was about 10 times more luminous than a typical supernova resulting from the collapse of a massive star, adding to the class of luminous supernovae that have been discovered recently with optical surveys. Different explanations have been proposed to explain these energetic supernovae, including (1) the interaction of the supernova’s blast wave with a dense shell of matter around the pre-supernova star; (2) radioactivity resulting from a pair-instability supernova — triggered by the conversion of gamma rays into particle and anti-particle pairs; (3) emission powered by a neutron star with an unusually powerful magnetic field.

In the first Chandra observation of SN 2010jl, the X-rays from the explosion’s blast wave were strongly absorbed by a cocoon of dense gas around the supernova. This cocoon was formed by gas blown away from the massive star before it exploded.

In the second observation taken almost a year later, there is much less absorption of X-ray emission, indicating that the blast wave from the explosion has broken out of the surrounding cocoon. The Chandra data show that the gas emitting the X-rays has a high temperature — greater than 180 million degrees Fahrenheit (100 million degrees Celsius) — strong evidence that it has been heated by the supernova blast wave.

The energy distribution, or spectrum, of SN 2010jl in optical light reveals features that the researchers think are explained by the following scenario: Matter around the supernova has been heated and ionized — electrons stripped from atoms — by X-rays generated when the blast wave plows through this material. While this type of interaction has been proposed before, the new observations directly show, for the first time, that this is happening.

This discovery therefore supports the idea that some of the unusually luminous supernovas are caused by the blast wave from their explosion ramming into the material around it.

In a rare example of a cosmic coincidence, analysis of the X-rays from the supernova shows that there is a second unrelated source at almost the same location as the supernova. These two sources strongly overlap one another as seen on the sky. This second source is likely to be an ultraluminous X-ray source, possibly containing an unusually heavy stellar-mass black hole, or an intermediate-mass black hole.
