A brief history of black holes

The 1964 discovery of Cygnus X-1 filled in a missing piece of Einstein’s puzzle and widened our understanding of the universe.
By | Published: August 29, 2019 | Last updated on May 18, 2023
In this artist’s depiction of Cygnus X-1, a stellar-mass black hole strips gas from the surface of its companion star as they orbit each other. Since the 1970s, it has since become the strongest black hole candidate, with scientists at near certainty that it is one. Initially detected in X-ray, it has since been studied in various other spectra.
Adolf Schaller for Astronomy
The foundation for what we know about black holes came during the Great War. Imagine the scene: December 1915. Europe and the world are struggling under the dark cloud of World War I. Somewhere on the eastern front, an older German artillery lieutenant huddles in his greatcoat, fighting to stay warm and dry at the bottom of a trench.

With numb and trembling fingers, he opens the latest dispatches from home. One particularly bulky package attracts his attention. That night, throwing caution to the wind, he risks using an electric light to read the long and detailed report. Little does he know that it will prove to be arguably the most important work of creative genius of the 20th century.

The author of this pivotal document was a theoretical physicist named Albert Einstein. The recipient was his colleague Karl Schwarzschild, the director of the Astrophysical Observatory in Potsdam and an accomplished theorist and mathematician. Despite his astronomical career, Schwarzschild, then in his 40s, joined the war effort.

Just weeks before, Einstein had completed 10 long years of dedicated work, successfully expanding his special theory of relativity to include gravitational forces along with electricity and magnetism. In four landmark papers published in the Proceedings of the Prussian Academy of Sciences, Einstein laid out the mathematical foundation of the general theory of relativity, still considered one of the most beautiful and elegant scientific theories of all time.

Albert Einstein developed his theory of gravity, known as general relativity, in 1915.
Albert Einstein Archives
The pinnacle of this magnum opus was published November 25, 1915, with the concise title “The Field Equations of Gravitation.” While perhaps a bit opaque to anyone without a firm grasp of tensor calculus, the field equations can be neatly summarized by the words of the great physicist John Wheeler: “Space-time tells matter how to move; matter tells space-time how to curve.”

Much like M. C. Escher’s famous picture of two hands sketching each other, the circular reasoning of Einstein’s field equations makes them both elegant, yet also notoriously difficult to solve. At the root of this difficulty is Einstein’s far more famous equation E=mc2, which states that energy and matter are interchangeable. Because gravity is a form of energy, it can behave like matter, creating yet more gravity. Mathematically speaking, general relativity is a nonlinear system. And nonlinear systems are really hard to solve.

It’s easy to imagine Einstein’s shock when, amid a dreadful war, Schwarzschild wrote back within a matter of days, describing the first known solution to Einstein’s field equations. Schwarzschild modestly writes, “As you see, the war treated me kindly enough, in spite of the heavy gunfire, to allow me to get away from it all and take this walk in the land of your ideas.” Einstein responds, “I have read your paper with the utmost interest. I had not expected that one could formulate the exact solution of the problem in such a simple way. I liked very much your mathematical treatment of the subject.”

Tragically, less than a year later, Schwarzschild succumbed to a skin disease contracted on the front, joining the millions of WWI fatalities due to disease. He left behind a solution that completely describes how space-time is warped outside a spherical object like a planet or star. One of the features of this mathematical solution is that for very compact, high-density stars, it becomes much harder to escape the gravitational field of the star. Eventually, there comes a point where every particle, even light, becomes gravitationally trapped. This point of no escape is called the event horizon. As one approaches the event horizon, time slows to a complete standstill.

Karl Schwarzschild developed the idea for black holes from relativity’s equations in 1916, just a year after Einstein published his theory.
Emilio Segre Archive
For this reason, early physicists studying these bizarre objects often called them “frozen stars.” Today, we know them by the name first used by Wheeler in 1967: black holes. Even though the event horizon played an integral part in Schwarzschild’s solution, it took many years before black holes were accepted as anything other than a mathematical curiosity. Most of the world’s leading experts in general relativity in the first half of the 20th century were absolutely convinced that black holes could never form in reality. Arthur Eddington insisted, “There should be a law of nature to prevent a star from behaving in this absurd way.”

Complicating the issue was the concurrent development of quantum mechanics, a new field almost entirely characterized by cases of nature behaving absurdly. Physicists working at the intersection of quantum mechanics and general relativity began to appreciate how both fields were critically important to understanding very massive and dense stars. But the bizarre nature of these new branches of physics strained even the most gifted intuition, so that even 50 years after Schwarzschild’s landmark paper, there was still no consensus on the existence of black holes.

Find the unseeable

One thing was clear: If black holes did exist, they were most likely formed by the collapse of massive stars, unable to support their own weight after running out of nuclear fuel. The question most astronomers were focused on was, “How do we find them?” After all, black holes give off no light of their own. Astronomy needs light, and to make light, you generally need matter — the hotter and brighter, the better.

Fortuitously, the late 1960s marked the dawn of X-ray astronomy with a series of sounding rockets and satellites that could get above Earth’s atmosphere, which otherwise blocks out all celestial X-rays.

During a short rocket flight in 1964, astronomers discovered one of the brightest X-ray sources in the sky, in the constellation Cygnus, dubbed Cygnus X-1 (Cyg X-1 for short). However, it didn’t coincide with any particularly bright optical or radio source, leaving its physical origin a mystery. When NASA’s Uhuru X-ray Explorer Satellite was launched in 1970, more detailed observations became possible, narrowing the uncertainty of its location. One of the first remarkable discoveries was Cyg X-1’s rapid variability, on timescales shorter than a second. This strongly suggested that the physical size of the X-ray-emitting region was quite compact, much smaller than a typical star. What could possibly pack so much power into such a small area?

Cygnus X-1 (the brighter of the stars by the arrow) lies in a rich field near the plane of the Milky Way, and doesn’t look like much at visible wavelengths.
Within a year, a stellar counterpart to Cyg X-1 was identified, allowing astronomers to confirm it as a binary system and estimate the mass of the companion by measuring the Doppler shift of the orbiting star’s spectrum. The answer was a whopping 15 times the mass of the Sun, far exceeding any theoretical limit for white dwarfs or neutron stars. Altogether, the rapid time variability, large X-ray luminosity, and high mass estimate combined to make Cyg X-1 an excellent candidate for the first stellar-mass black hole. (Strong evidence for supermassive black holes also had been building for years, thanks largely to Maarten Schmidt’s study of quasars. Their tremendous brightness and great distances combined to make a strong case for black hole accretion, the only imaginable energy source capable of such incredible luminosity.)

As more sensitive X-ray telescopes were launched in subsequent years, the case only grew stronger. We have now seen X-ray variability from Cyg X-1 on timescales as short as a millisecond, confining the emission region to an extent of hundreds of kilometers, just a few times the size of the event horizon. By observing X-rays from black holes, we can directly probe the properties of space-time predicted by general relativity.

Cygnus X-1 first came to notice when astronomers found it to be an intense source of X-rays. In this view from the Chandra X-ray Observatory, the high-energy radiation is colored blue.

Staring down an event horizon

While stellar-mass black holes are some of the brightest X-ray sources in the sky, they are also some of the most fickle. In the 40-plus years since the discovery that Cyg X-1 is likely a black hole, only a few dozen more black hole candidates have been identified. Most of those have only been detectable during short, unpredictable outbursts lasting a month or so before they disappear again for decades. Compare that with their supermassive counterparts: The Sloan Digital Sky Survey alone has identified more than 100,000 quasars (the energetic centers of young, distant galaxies), each powered by an accreting supermassive black hole.

In addition to this most common “quiescent” behavior, astronomers have identified three other major states exhibited by stellar-mass black holes: hard, soft, and intermediate. These names describe the observable properties of the X-ray spectra in each state. We aren’t yet entirely certain what physical mechanisms drive these different behaviors, but they are likely tied to two things: how much gas the black hole is accreting, and how strong the magnetic fields embedded in the gas are.

In astronomical jargon, a “hard” spectrum means we see more high-energy X-rays than low-energy, and “soft” is the opposite. Of course, even “low-energy” is a relative term, as these photons come from an accretion disk that is at a temperature of millions of degrees, compared with the corona, which boasts a temperature in excess of 1 billion degrees!

The intermediate state shows evidence of a thin, cool accretion disk surrounded by a hot, diffuse corona like the surface of our own Sun. In this state, the high-energy X-rays coming from the corona shine down on the disk. Some of these X-rays get absorbed by the trace amounts of iron mixed in the disk’s gases. The iron then shines just like the fluorescent gas in a neon light, giving off more X-rays at very specific wavelengths. Because the gas in the disk is orbiting the black hole at nearly the speed of light, the X-rays coming from the disk experience extreme Doppler shifts, appearing to a distant observer at shorter wavelengths when the gas is moving toward the observer and longer wavelengths when moving away. By carefully measuring the wavelengths of the X-rays from an accreting black hole, we can measure how fast all the gas is orbiting around it.

Original spin

Considering the first solution to Einstein’s field equations took Schwarzschild less than a week to derive, it must have felt like an eternity to wait nearly a half-century before the next black hole solution was discovered by New Zealander Roy Kerr in 1963. (Another solution, the Reissner-Nordstrom black hole, was published almost immediately after Schwarzschild’s, but also is limited to spherically symmetric systems and mathematically almost identical.) Kerr made his formulation while at the University of Texas at Austin.

Unlike Schwarzschild black holes, Kerr black holes spin; they retain the angular momentum from the pre-supernova star from which they were born. This is extremely important astrophysically, since we know that nearly every celestial object rotates, from moons to planets to galaxies. So it is natural to expect that black holes rotate, too.

Evidence for this spin shows in how the black hole pulls everything around the horizon, essentially sweeping up space-time itself into a swirling vortex. This allows gas to move ever faster as it spirals closer and closer to the horizon, leading to more extreme Doppler shifts, and thus larger offsets in the X-ray spectra. In just the past few years since the launch of NASA’s NuSTAR X-ray telescope, we have been able to use these spectra to measure spins of multiple black holes with unprecedented accuracy. NuSTAR’s ability to see X-rays covering a much wider range of energies compared with previous missions also allows us to rule out other alternative models — like X-ray absorption by interstellar gas clouds — that had been proposed to explain the shape of the spectrum.

Measuring black hole spins not only teaches us about general relativity, but it also provides important insight into how massive stars evolve and collapse in supernovae. Because many of these binary systems are quite young (at least by cosmic standards — Cyg X-1 is “only” a few million years old), whatever spin we measure today is essentially the same spin that came from the original formation. From this point of view, they truly are “frozen stars,” retaining a near-perfect memory of their violent birth.

An outrageous legacy

General relativity is one of the few fields in modern physics where theory has driven experimentation for almost the entire century. Einstein had a unique talent for not only proposing brilliant and fruitful thought experiments, but also real experiments that could test his theories. Perhaps his most famous prediction was how the gravity of the Sun would deflect the light from distant stars, an effect confirmed with spectacular success in 1919 during a solar eclipse, propelling Einstein to international celebrity. More impressive still was the 40-plus years between Schwarzschild’s (unintentional) prediction of black holes and the discovery of Cyg X-1.

To borrow a phrase from theoretical physicist Kip Thorne, perhaps the most outrageous piece of Einstein’s legacy was his prediction of gravitational waves, made a century ago, and triumphantly confirmed just this year by the Laser Interferometer Gravitational-wave Observatory (LIGO). In addition to confirming the basic idea that the “fabric” of space-time is not just a metaphor but a tangible substance, the LIGO discovery also provided a new test of general relativity in the most extreme environment — just outside a black hole. There were some surprises in store, as well: the discovery of stellar-mass black holes 30 times the mass of the Sun, twice as big as any seen before. For the cherry on top, LIGO was even able to measure the spin of the final black hole at 70 percent of the maximum Kerr limit, arguably the most accurate and precise measure of spin to date.

This simulation gives a realistic depiction of a black accretion disk, including the light-bending effects
of relativity.
NASA/Jeremy Schnittman
Building on this unprecedented track record of success, most astrophysicists fully believe that general relativity’s description of the nature of black holes is the correct one. Lingering questions attempt to use our knowledge of black holes to improve our understanding of how gas, magnetic fields, and X-rays behave in the presence of such a tremendous gravitational force. This is the messy part of black hole research — Astronomer Royal Martin Rees famously described it as “mud wrestling” — and one where observation has been far ahead of theory for decades.

The first puzzle came right on the heels of the first detection of Cyg X-1. In 1973, from the most basic laws of conservation of energy and angular momentum, Igor Novikov and Kip Thorne derived a brilliant and elegant description of how gas slowly spirals in toward a black hole, releasing its gravitational potential energy as heat and radiation at temperatures of millions of degrees.

There are only two problems with the Novikov-Thorne model: It doesn’t work in theory, and it doesn’t work in practice. It doesn’t work in theory because it doesn’t explain how exactly the gas loses angular momentum. It doesn’t work in practice because it doesn’t agree with observations of high-energy X-rays coming from billion-degree gas.

Hot ionized gas experiences almost no friction or viscosity, so it should simply go around and around on perfectly circular orbits forever, never getting any closer to the event horizon. Novikov and Thorne fully appreciated this problem, and they absorbed it into their theory with a simple fudge factor, leaving the details to later work. In the end, it took almost 20 years to find the answer. In 1991, Steve Balbus and John Hawley discovered a powerful instability that comes from the twisting and pulling of magnetic field lines embedded in an accretion disk. Ionized gas is an excellent electrical conductor, which means it also can generate powerful magnetic fields. These fields, in turn, can pull back on the gas, slowing it down and allowing it to spiral in toward the black hole.

By 2001, supercomputers had become powerful enough to adequately simulate the Balbus-Hawley instability in accretion disks around realistic black holes, fully confirming their predictions. It took yet another decade before the simulations were sophisticated enough to include the effects of radiation, and study the interplay between the disk and corona. In doing so, we have finally reached the point where, starting from the most fundamental laws of nature, we can explain how the high-energy X-rays, first seen in 1971, are actually generated around real black holes.

In exactly 100 years, black holes have progressed from being a mathematical curiosity, to the subject of purely theoretical physics, to a central area of astronomy research, where theory and computer simulations confront experiments and observations on a daily basis. With the recent opening of the gravitational-wave window on the universe, in the coming years we fully expect to learn even more about the birth, life, and death of these remarkable objects. One thing we can say for certain: We will continue to be surprised by nature’s exotic imagination!
