From the July 2005 issue

A meeting with a comet

On July 4, 2005, a comet and a NASA probe collided. Did astronomers find what they were looking for under the comet's surface?
By | Published: July 25, 2005 | Last updated on May 18, 2023

Deep Impact mosaic
The camera on the copper probe captured a sequence of images as it approached Tempel 1. The most detailed image was taken 3 seconds before impact, 18.6 miles (30 km) above the comet.
NASA
In Evolution at the edge, S. Alan Stern describes many ways in which comets are not quite pristine relics of the early solar system. The first mechanism he describes that affects comet nuclei is the damage caused by solar and galactic radiation. This radiation creates a rind around a comet’s nucleus anywhere from a few inches to a few yards thick. Exactly how thick was one of the questions NASA’s Deep Impact probe addressed.

As the 820-pound (370 kilogram) copper probe zoomed toward its target — Comet 9P/Tempel 1 — a camera on the probe captured its descent. Scientists were able to resolve objects on Tempel 1’s surface 13 feet (4 meters) in diameter — 10 times more detailed than ever seen before.

Once the probe plowed into Tempel 1 — at 23,000 mph (37,000 km/h) — two cameras on the Deep Impact mothership watched and recorded the impact’s aftermath. Even ground-based telescopes imaged the impact it was so bright.

False-color Tempel 1
The Deep Impact mothership took this false-color image 50 minutes after impact, as it began its journey away from Tempel 1. The colors correspond to brightness, with white indicating the brightest areas. The plume of powdery material is on the right side of Tempel 1 in this view.
NASA/JPL-Caltech/UMD
When the probe slammed into the comet, a large cloud of material shot up at roughly 11,000 mph (18,000 km/h). After analysis, it appears Tempel 1’s surface is covered with powdery material. Small particles reflect more sunlight, which accounts for the plume’s brightness.

The cloud of material dissipated after 10 days, and as of now, astronomers are trying to find the crater.

Astronomers detected only a small amount of water vapor and other gases. In fact, the comet had a post-impact water-vapor emission rate similar to pre-impact rates, according to astronomers observing with the Submillimeter Wave Astronomy Satellite. This implies the probe didn’t create a crater deep enough to see below the rind. So the radiation-damaged surface must extend deeper than just a few yards.

What really happens to comet nuclei out in space? Astronomers have analyzed the surfaces of four comets through spacecraft flybys, none of which looks alike. Slamming a projectile into one didn’t quite unlock as many secrets as we hoped, but landing on one might. Here’s to the Rosetta comet mission and its spacecraft — Philae — that will land on a comet’s surface.

Rosetta was launched in March 2004, and Philae is projected to land on comet 67P/Churyumov-Gerasimenko in the summer of 2014. Let’s keep our fingers crossed for this one.
